CPL 02-02-079, Appendix F

HCS Pictograms and Hazards

Scale up your procedures with Soxhlet extractors from Safety Emporium.

Health Hazard

health hazard pictogram

Flame

Flame pictogram

Flammables
Pyrophorics
Self-Heating
Emits Flammable Gas
Self-Reactives
Organic Peroxides

Exclamation Mark

Exclamation mark pictogram

Irritant (skin and eye)
Skin Sensitizer
Acute Toxicity (harmful)
Narcotic Effects
Respiratory Tract Irritant
Hazardous to Ozone Layer
(Non-Mandatory)

Gas Cylinder

gas cylinder pictogram

Gases Under Pressure

Corrosion

Corrosion pictogram

Skin Corrosion/Burns
Eye Damage
Corrosive to Metals

Exploding Bomb

Exploding bomb pictogram

Explosives
Self-Reactives
Organic Peroxides

Flame over Circle

flame over circle pictogram

Oxidizers

Environment
(Non-Mandatory)

Environment pictogram

Aquatic Toxicity

Skull and Crossbones

Skull and crossbones pictogram

Acute Toxicity (fatal or toxic)

Note: Self-reactive chemicals and organic peroxides have the possibility of being labeled with two different pictograms depending upon the severity of the reaction.
